Mao Hui Machinery, as a professional supplier of automation components in China, offers a variety of motor products. The Schneider ILM1003P01A0000 belongs to the Schneider Electric Lexium ILM/PacDrive 3 series of integrated servo motors. It is a fully integrated servo solution that integrates the motor, driver, power supply, and feedback circuit into one.
Unlike the traditional split servo motor + driver kit, the ILM integrated servo system can significantly reduce the wiring in the control cabinet, save up to 90% of the control cabinet space, and shorten the wiring time by 70%. It is particularly suitable for compact multi-axis automation equipment.
| Model | ILM1003P01A0000 |
| Flange size | 100mm |
| Stator structure | 3-stack |
| Rated power | 1100W (1.1kW) |
| Rated speed | 3000 rpm |
| Continuous locked rotor torque | 5.8 Nm |
| Peak torque | 28.3 Nm |
| Rated continuous current | 3.6 A |
| Encoder | Single-turn Hiperface SinCos absolute value encoder |
| Brake function | No holding brake |
| Protection class | IP65 |
| Cooling method | Natural convection cooling |
| Communication method | SERCOS III |
The Schneider ILM1003P01A0000 has a rated power of 1.1kW, a continuous locked torque of 5.8Nm, a maximum mechanical speed of 3000rpm, is equipped with a single-turn sinusoidal and cosine Hiperface absolute value encoder, features a key-controlled shaft design, has no braking function, and has a protection grade of IP65. The standard installation flange diameter is 100mm. It adopts the natural convection cooling method and can be perfectly matched with the PacDrive LMC motion controller through the SERCOS communication bus.
Layered long-term warranty:
The brand-new original complete machine comes with a 12-month warranty, covering the internal drives, motors and encoder core components;
The disassembled tested model offers a 6-month functional warranty; for faults not caused by human factors, free replacement is provided within 7 days after delivery, and maintenance fees are waived for faults within the warranty period. 7×16-hour exclusive control system technical support is provided, with dedicated engineers for the ILM series capable of remotely solving issues such as alarms, EtherCAT communication, zeroing anomalies, and parameter debugging; the order includes original manuals, wiring diagrams, and debugging parameter templates. One-stop support + customs clearance documents
A complete set of ILM hybrid power cables, installation brackets, LMC controllers, and complete replacement models of the same series are provided to ensure the equipment is complete; COO origin certificates, packing lists, and CE/RoHS certifications are provided for free, facilitating customs clearance at overseas ports; bulk purchases can be made from the factory, with prices increasing step by step, and a locked price is offered for long-term cooperation.
The motor, drive function, power module and feedback system are integrated in the same unit, reducing the need for external installation components.
The integrated structure can reduce the internal space requirements of the control cabinet and make the design of mechanical equipment more flexible.
In multi-axis automated equipment, the Schneider ILM1003P01A0000 can reduce complex wiring through a distributed installation method, improving the overall integration efficiency of the equipment.
Combined with the absolute value encoder feedback, it meets the needs of the equipment for accurate positioning and repetitive motion.
A: Only support Schneider PacDrive3 LMC series controllers via Sercos bus, not compatible with EtherCAT/MODBUS native.
A: Suffix "A" means no holding brake, if brake required select model end with 32.
A: Smooth unkeyed shaft, keyed version model code is ILM1003P11A0000.
A: Original new sealed stock available; spot goods ship in 2-3 days, bulk factory lead time 6 weeks, NCNR non-cancelable.
ILM1003P01F0000
ILM1003P02A0000
ILM1003P02F0000
ILM1003P11A0000
ILM1003P11F0000
ILM1003P12A0000
ILM1003P12F0000
ILM1003P01A0000
